Performance parameter

1, basic function the flexible endoscope can be washed and disinfected completely and automatically according to six basic steps: first washing → enzyme washing → second washing → disinfection → last washing → drying, and spray alcohol into the endoscopic lumen, blow-dry the internal residual liquid, to reach the high level of endoscopic disinfection requirements, in line with the"Soft endoscopic cleaning and disinfection technical specifications" requirements.

Performance Characteristics

1. Appearance and structure

1) the endoscope automatically cleans the top cover of the transparent toughened glass of the sterilizer to directly monitor the whole process of cleaning and disinfection

2) the foot-controlled laser sensor switch with the electric support rod to avoid the need to touch the top cover during the whole process to prevent secondary contamination

3) the machine is designed with a liquid window and a background light to make the alcohol and biological enzyme stocks visible at all times, and the electronic level alarm system to achieve the most intuitive understanding of the use of liquid

 4) the disinfection liquid storage tank can store the disinfection liquid capacity: 15 L

5) the tank volume is about 12 l, after actual testing, the disinfection liquid can be used more than 100 times

6) it is applicable to most of the market endoscope cleaning disinfectants and multi-enzyme detergents;

(7) advanced cleaning tank structure design, size: 390 * 410 * 160mm, under the premise of ensuring effective space, not only let the endoscope posture stretch, but also effectively save disinfectant, disinfectant full immersion 12.5 L,

 8) open-type disinfectant: can use common Peracetic acid, phthalaldehyde, glutaraldehyde disinfectant,

9) built-in power-free rotating sprinkler device, the external surface of the endoscope to carry out rotating spray cleaning, so that more thorough cleaning, and energy-saving failure rate is lower;

10) unique pipeline design, so that the cleaning process to minimize residual liquid, reduce the harm of liquid mixing, to maximize the effective use of disinfectant concentration, effectively prevent the possibility of cross-infection;

11) built-in 0.2 μm aperture PET material air filtration system, which can effectively block the air drying bacteria, viruses, to prevent secondary pollution;

12) all the accessories are made of plastic and SUS 316 stainless steel materials, effectively resist the corrosion of disinfectant;

13) machine size: 580 × 750 × 960(mm) , weight 81 kg;

14) built-in water treatment ozone generator, to ensure that the water quality of the machine up to standard; the shape of the design is square, beautiful, can be a number of machines closely discharge, effectively saving space.

15) the appearance design is square, beautiful, may several machines closely discharge, effectively saves the space.

2. Function

1) unique control system design, the combination of color LCD touch screen and touch-type shortcut keys, so that the setting of inquiry function and use function keys separated, more in line with the requirements of the hospital and user operation needs;

A) color LCD touch screen: draw lessons from Win10 System's design interface and Android system's setup menu, build a unique operating system, set logic, convenience, science, simplicity, security in one, the best experience to contribute to medical workers; B) the screen function area is clear, the top is the lintel area, mainly trademarks, time, temperature, etc. ; the middle shows the setting control area; the bottom is the prompt area; the interface is clean, easy to identify;

c) touch-type quick keys, one-click start cleaning procedures, convenient and fast;

D) reliable and safe design, managers and operators of functional authority clear, so that the cleaning accuracy in the hands of managers, reducing medical malfunctions and medical disputes.

2) the machine is equipped with automatic lock screen and lock key function

3) traceability function: the machine has its own IC card reader, which can record the endoscope identity number and operator number, and the two can be bound during the cleaning process to achieve the traceability of cleaning and disinfection of the endoscope

4) emergency drainage: emergency drainage can be carried out, re-cleaning procedures; 5) blockage detection: when the endoscope pipe is blocked, send an alarm signal and screen alert;

6) leak detection: before each cleaning procedure and the entire cleaning process can be carried out for leak detection, function optional, when detected, send an alarm signal, LCD screen display maintenance tips;

7) with ultrasonic cleaning function and equipped with basket, can carry out ultrasonic cleaning of small endoscopic accessories

8) enzyme solution ratio management: set the enzyme solution configuration ratio, automatically calculate the amount of enzyme solution;

9) disinfectant management: according to different types of disinfectant use standards, can set the number of times and days, tips expired disinfectant and automatic discharge expired disinfectant;

10) waste liquid recovery: expired disinfectant recovery function; alcohol blow-dry: alcohol injection time, blow-dry time in seconds (s) as a unit can be adjusted.

12) disinfection barrel cleaning: when the user replaces different types of disinfectant or forms dirt or crystals due to the prolonged use of the disinfectant storage barrel, the entire machine liquid pipeline and the disinfection solution storage barrel are cleaned by using not more than 45 ° C of hot water;

13) the first washing, the second washing and the last cleaning water are all one-time flow of water;

14) self-pipeline disinfection: independent button, one-button start the cleaning and disinfection of this machine circulation pipeline washing; washing package: can provide 3 BASIC + 4 sets of optional package, fully meet the needs of users;

15) washing set: can provide 3 sets of BASIC + 4 sets of optional set meal, fully meet user needs;

16) wash enhancement: exclusive design to enhance the washing function, wash the end of a repeat, in order to achieve better cleaning effect;

17) automatic printing: each completed a washing process, the device automatically print this washing records;

18) data query download: Powerful Information Query, storage, analysis and processing functions, every cleaning information, regardless of success or failure are recorded for leaders to analyze and query

19) USB function: you can use U disk to download the finished cleaning records;

20) built-in WIFI wireless transmission function, can clean data sent to the traceability system through the wireless network host, do cleaning workstation, endoscope automatic cleaning and disinfection machine, data traceability system, hospital network of the full iot, seamless link;

21) the whole process of failure alarm tips: divided into screen icon flashing alarm and screen pop-up alarm interface, intuitive reflection of the alarm reasons, including: enzyme liquid insufficient alarm tips, alcohol insufficient alarm tips, disinfectant insufficient alarm tips, disinfectant expired alarm tips, blocking alarm and pipeline unconnected alarm, water pressure insufficient alarm, washing temperature alarm;

22) double level control, once the first level device fails, the second level device immediately replenishes the control, effectively preventing the liquid overflow of the cleaning tank;

23) the mature overstep control system, when the machine appears the breakdown, quickly stops the operation and opens the machine cover, takes out the endoscope;

24) the machine has built-in disinfection liquid volatile gas analysis device, automatically decomposes the disinfection liquid volatile gas, effectively protects the gas volatilization to cause harm to the human;

25) the entire cleaning and disinfection process ≤17 minutes.
