Technical parameters:

1. Water yield: ≥2000L/H

2. Water quality: according to WS507-2016 soft endoscope cleaning and disinfection technical specifications, conductivity ≤10 us/cm (25 ° C) , colony count ≤10 cfu/100 ml

3. Power: AC220V/50HZ POWER: 3000W

4. Working Temperature: 2-45 ° C

 5. Ion removal rate ≥99%

6. Water use efficiency ≥70%

7. Water storage capacity of pure water tank: 1000L

8. Standard features:

1) automatic cleaning and maintenance function of the reverse osmosis host, with automatic pulse washing function

2) automatic operation control, automatic start and stop, to achieve unattended

3) pre-processing system with automatic and manual washing, regeneration function

4) with water-free protection, pressure protection and other security self-locking devices 5) intelligent balance system to ensure the stability and safety of the operation of the equipment

6) system uses a variety of combination of sterilization and disinfection mode, automatic timing washing disinfection

9. The whole process of the control system is controlled by microcomputer, and the process flow, the running status of each component and the conductivity are displayed on-line by touch screen

10. Equipment Process: pretreatment + RO + constant pressure water supply system + ultraviolet sterilization and Ozone Sterilizer

1) Pretreatment System: Pretreatment system consists of softening filter, security filter: filter material for strong acid cation resin, flow rate ≥2 m3/h tank body specification is 1354 resin tank control valve for automatic regeneration control valve

2) reverse osmosis part of high pressure pump requirements: adopt domestic well-known brands, pump head material is stainless steel, flow rate ≥2 m3/h, lift ≥100 m membrane components requirements: desalination rate ≥99% type of membrane: imported aromatic polyamide composite membrane, quantity: 8, single RO membrane water production ≥300 l/h/branch

3) purified water supply system pure water pump requirements: material is stainless steel, flow rate ≥2m3/h, head ≥40m health-grade stainless steel water tank: volume is 1000L, equipped with liquid level device, through the liquid level controller to achieve reverse osmosis device and pure water external delivery pump start and stop; equipped with breathing apparatus, can filter the particles and bacteria in the gas, to avoid pure water and air direct contact caused by the total number of colonies exceed the standard;

4) constant pressure system: imported constant pressure water supply system control: the dual control by the tank level and pressure controller, in order to achieve the balance of the whole system, stable operation and water shortage protection of pure water pump

11. System piping: high quality U-PVC
